Crater A-450
Bottom-Feed Automatic Cutting Machine, Ø450 mm
Bottom-Feed Automatic Cutting Machine Ø450 mm Locally manufactured in accordance with CE standards for the automatic cutting of large-sized aluminum and PVC profiles - whether straight or angled - using a Ø450 mm bottom-…
Devamını oku
Read More
İndirmeler ve kaynaklar Downloads & resources
Hızlı Yanıt
Fast Response
24 saat içinde teklif
Quote within 24 hours
Türkiye'den Dünyaya
From Turkey to the World
Türkiye üretim, global sevkiyat
Made in Turkey, shipped worldwide
Manufactured domestically in accordance with CE standards for the automatic cutting of large-sized aluminum and PVC profiles - whether straight or angled - using a Ø450 mm bottom-feed saw.
- Dual-hand safety system
- Heavy-duty machine frame
- 90° cutting capability on the left side
- Movable miter gauge
- Capability to cut at intermediate angles in addition to standard angles
- The saw blade ejection is hydro-pneumatic, and the ejection speed is adjustable
| Cutting Motor: | 2.2 kW, 3 HP , 400 V–230 V, 50/60 Hz |
| Saw Dimensions: | D=450 mm, d=30–32 mm |
| Saw: | 3000 |
| bar / Air liters: | 6–8 bar, 20 L/min |
| Package Dimensions: | 90 x 106 x 154 cm |
| Machine Dimensions: | 80 x 96 x 138 cm |
| Machine Weight (kg): | 244 |
- 1 450 mm saw
- 2 vertical pneumatic clamps
- Air gun
- Conveyor
- Oil spray system
- Horizontal clamps
- Chip extraction manifold
- Foot-pedal control system
- Automatic top cover
- Single-phase motor
Teknik özellikler ve donanımlar önceden haber verilmeksizin değiştirilebilir. Technical specifications and features are subject to change without prior notice.
