Crater A-550
Bottom-Feed Automatic Cutting Machine, Ø550 mm
The Altan Automatic Cutting Machine, equipped with a 550 mm saw blade, is manufactured domestically in accordance with CE standards for the automatic cutting of aluminum and PVC profiles.
Devamını oku
Read More
İndirmeler ve kaynaklar Downloads & resources
Hızlı Yanıt
Fast Response
24 saat içinde teklif
Quote within 24 hours
Türkiye'den Dünyaya
From Turkey to the World
Türkiye üretim, global sevkiyat
Made in Turkey, shipped worldwide
The Altan Automatic Cutting Machine, equipped with a 550 mm saw blade, is locally manufactured in accordance with CE standards for the automatic cutting of aluminum and PVC profiles.
- Robust machine body
- Higher cutting capacity compared to competitors
- Dual-hand safety system
- Ability to cut at standard angles and intermediate angles
- More powerful vacuum system with a single manifold
- The saw blade ejection is hydro-pneumatic, and the ejection speed is adjustable
- Internal LED lighting
- Standard angles on the right and left sides: 75°, 60°, 45°, 30°, 22.5°, 15°, 0°
| Cutting Motor: |
4.0 kW, 5.5 HP , 400 V, 50/60 Hz |
| Saw Dimensions: | D=550 mm, d=30–32 mm |
| Saw: | 2500 |
| bar / Air liters: | 6–8 bar, 30 L/min |
| Package Dimensions: | 142 x 122 x 155 cm |
| Machine Dimensions: | 150 x 130 x 157 cm |
| Machine Weight (kg): | 480 |
- 1 Ø550 mm saw
- 2 vertical vises
- 1 horizontal vise
- Air gun
- Oil spray system
- Automatic opening top cover
- Conveyor
- + 1 horizontal vise
- Chip collection manifold
Teknik özellikler ve donanımlar önceden haber verilmeksizin değiştirilebilir. Technical specifications and features are subject to change without prior notice.
