Crater A-700/A-760
Bottom-Feed Automatic Cutting Machine Ø700/760 mm
These aluminum and PVC profiles are manufactured domestically in accordance with CE standards for automatic cutting at all angles and to the desired length using a 700/760 mm saw.
Devamını oku
Read More
İndirmeler ve kaynaklar Downloads & resources
Hızlı Yanıt
Fast Response
24 saat içinde teklif
Quote within 24 hours
Türkiye'den Dünyaya
From Turkey to the World
Türkiye üretim, global sevkiyat
Made in Turkey, shipped worldwide
Aluminum and PVC profiles are manufactured domestically in accordance with CE standards for automatic cutting at all angles and to the desired length using a 700/760 mm saw.
- Robust machine frame
- Dual-hand safety system
- Cutting capability at standard angles and intermediate angles
- More powerful chip vacuum system with a single manifold
- The saw exit is hydro-pneumatic, and the exit speed is adjustable
- Internal LED lighting
- Standard angles on the right and left sides: 75°, 60°, 45°, 30°, 22.5°, 15°, 0°
- Rotation angles can be adjusted to any angle between -75° (left) and +75°
Crater A-700
| Cutting Motor: | 5.5 kW, 7.5 HP,
400 V , 3-phase, 50/60 Hz |
| Saw Dimensions: | D=700 mm, d=38 mm |
| Saw: | 2000 rpm |
| Bar / Air liters: | 6–8 bar, 140 liters/min |
| Package Dimensions: | 162 x 145 x 195 cm |
| Machine Dimensions: | 205 x 174 x 169 cm |
| Machine Weight (kg): | 650 kg |
Crater A-760
| Cutting Motor: | 5.5 kW, 7.5 HP,
400 V , 3-phase, 50/60 Hz |
| Saw Dimensions: | D=760 mm, d=38 mm |
| Saw: | 2000 rpm |
| Bar / Air liters: | 6–8 bar, 150 liters/minute |
| Package Dimensions: | 162 x 145 x 195 cm |
| Machine Dimensions: | 205 x 174 x 169 cm |
| Machine Weight (kg): | 660 kg |
- 1 700/760 mm saw blade
- 2 vertical vises
- 1 horizontal vise
- Air gun
- Oil spray system
- Automatic-opening top cover
- Conveyor
- 1 horizontal vise
- Chip extraction manifold
Teknik özellikler ve donanımlar önceden haber verilmeksizin değiştirilebilir. Technical specifications and features are subject to change without prior notice.
